Need to have a trim ram resealed....

**kevnmcd** · 04-07-2014, 12:13 PM

Anyone know how hard it is to reseal the trim rams on a Bravo 1 drive? I have one that isn't holding when under way. It will slowly drop when the other on holds steady. I am assuming it just needs to have a new seal kit installed and just wondering how hard that would be to do myself? If it needs a bunch of special tools then may need to have a shop do it so anyone know how much that would cost?

**Cigalert** · 04-07-2014, 12:20 PM

I had the same problem. Pulled off the ram and ends up it was just loose.

I'd imagine even a new kit thrown on there couldn't be much hassle. As long as you don't release the tube from the pump fluid loss should be minimal. As far as bleeding it after....I have no idea.

**kevnmcd** · 04-07-2014, 12:22 PM

Bleeding was another question. I was assuming you just tightened everything back up and just actuated in up and down a few times. Anyone know?

**28eliminator** · 04-07-2014, 12:38 PM

I just did mine last weekend kevin.. it was pretty simple.

Seal kits were cheap.. like $20 bucks each. All you need is an adjustable spanner wrench and a 12 pack

**Paul65K** · 04-08-2014, 07:32 AM

Originally Posted by 28eliminator

All you need is an adjustable spanner wrench and a 12 pack

Here in the good ol' US of A we call those a "Crescent wrench"

Name: British.jpg
Views: 195
Size: 34.7 KB

**28eliminator** · 04-08-2014, 12:53 PM

Originally Posted by Paul65K

Here in the good ol' US of A we call those a "Crescent wrench"

So you call this a "Crescent Wrench"

Name: untitled.jpg
Views: 147
Size: 4.7 KB

**kevnmcd** · 04-07-2014, 12:58 PM

That is good to hear Dave. How did you bleed it once it was all hooked back up?

**Menace Marine** · 04-07-2014, 01:06 PM

No need to bleed it. Run it up and down and check the level. It's easy work. We charge $125 parts and labor to do both rams. If you do it yourself just take your time and pay attention to the three balls on the end of the valve. They like to roll away.

Sent from my iPhone using Tapatalk

**HypNautic** · 04-07-2014, 06:27 PM

Originally Posted by Menace Marine

No need to bleed it. Run it up and down and check the level. It's easy work. We charge $125 parts and labor to do both rams. If you do it yourself just take your time and pay attention to the three balls on the end of the valve. They like to roll away.

Sent from my iPhone using Tapatalk

So how often should these be rebuilt? Is it just a matter of if and when they don't seal? Or should we be looking at every 5-10-15 years?
